Model：F4A-Z8
category：Peristaltic pump filling system
Reference flow rate：0.008-2416mL/min
category：Peristaltic pump filling system
Reference flow rate：0.008-2416mL/min
Characteristic：
The filling system consists of 4 basic channels (expandable to 32 channels) and a controller, and YZ15 and YZ25 pump heads can be installedThe shell is made of stainless steel, corrosion resistant. Each channel has buttons and digital display, support online fine-tuning, convenient for customers to adjust the amount of liquid online. Each channel has its own function of stop-filling
The controller adopts a 7-inch (optional 8-inch) industrial touch screen, with clear display, convenient operation and optional language (switch between Chinese and English).
Home page: display filling parameters such as liquid quantity, time, pump head, hose, etc. Equipment working status indication; Accumulative filling times and zero clearing; Start - stop control of each channel and quick filling back - suction function
Imported motor driver chip, excellent performance
Circuit board all three anti - paint treatment, anti - corrosion, anti - moisture
Industry application：
Laboratory applicationPharmaceutical equipment
Food and beverage equipment
The environmental protection industry
? ?1. The filling system consists of 4 basic channels (expandable to 32 channels) and a
? ? ?controller, and YZ15 and YZ25 pump heads can be installed
? ?2. The shell is made of stainless steel, corrosion resistant. Each channel has
? ? ?buttons anddigital display, support online fine-tuning, convenient for customers
? ? ?to adjust theamount of liquid online Each channel has its own function of?stop
? ? ?filling
? ?3. The controller adopts a 7-inch (optional 8-inch) industrial touch screen, with
? ? ?cleardisplay, convenient operation and optional language (switch between Chinese
? ? ?and English).
? ?4. Interface home page: display filling parameters such as liquid quantity, time,
? ? ?pumphead, hose, etc.; Equipment working status indication; Accumulative filling
? ? ?times?andzero clearing; each Channel start - stop control and quick fill back -?
? ? ?up function
? ?5. Imported motor driver chip, excellent performance
? ?6. Circuit board all three anti-paint treatment, anti-corrosion, moisture-proof
